Drupal Salesforce Suite Custom Field Mapping Types

The Drupal 8 Salesforce Suite allows you to map Drupal entities to Salesforce objects using a 1-to-1 mapping. To do this it provides a series of field mapping types that allow you to select how you want to relate the data between the two systems. Each field type provides handling to help ensure the data is handled correctly on each side of the system.

As of this writing the suite provides six usable field mapping types:

  • Properties — The most common type to handle mapping data fields.
  • Record Type — A special handler to support Salesforce record type settings when needed.
  • Related IDs — Handles translating SFIDs to Drupal Entity IDs when two objects are related in both systems.
  • Related Properties — For handling properties across a relationship (when possible).
  • Constant — A constant value on the Drupal side that can be pushed to Salesforce.
  • Token — A value set via Drupal Token.

There is a seventh called Broken to handle mappings that have changed and need a fallback until its fixed. The salesforce_examples module also includes a very simple example called Hardcoded the shows how to create a mapping with a fixed value (similar to, but less powerful than, Constant field).

These six handle the vast majority of use cases but not all.  Fortunately the suite was designed using Drupal 8 annotated plugins , so you can add your own as needed. There is an example in the suite’s example module, and you can review the code of the ones that are included, but I think some people would find an overview helpful.

As an example I’m using the plugin I created to add support for related entities to the webform submodule of the suite (I’m referencing the patch in #10 cause that’s current as of this writing, but you should actually use whatever version is most recent or been accepted).

Like all good annotated plugins to tell Drupal about it all we have to do is create the file in the right place. In this case that is: [my_module_root]/src/Plugins/SalesforceMappingField/[ClassName] or more specifically: salesforce_webform/src/Plugin/SalesforceMappingField/WebformEntityElements.php

At the top of the file we need to define the namespace, add some use statements.

<?php

namespace Drupal\salesforce_webform\Plugin\SalesforceMappingField;

use Drupal\Core\Entity\EntityInterface;
use Drupal\Core\Form\FormStateInterface;
use Drupal\salesforce_mapping\Entity\SalesforceMappingInterface;
use Drupal\salesforce_mapping\SalesforceMappingFieldPluginBase;
use Drupal\salesforce_mapping\MappingConstants;

Next we need to provide the required annotation for the plugin manager to use. In this case it just provides the plugin’s ID, which needs to be unique across all plugins of this type, and a translated label.

/**
 * Adapter for Webform elements.
 *
 * @Plugin(
 *   id = "WebformEntityElements",
 *   label = @Translation("Webform entity elements")
 * )
 */

Now we define the class itself which must extend SalesforceMappingFieldPluginBase.

class WebformEntityElements extends SalesforceMappingFieldPluginBase {

With those things in place we can start the real work.  The mapping field plugins are made up of a few parts:

  • The configuration form elements which display on the mapping settings edit form.
  • A value function to provide the actual outbound value from the field.
  • Nice details to limit when the mapping should be used, and support dependency management.

The buildConfigurationForm function returns an array of form elements. The base class provides some basic pieces of that array that you should plan to use and modify. So first we call the function on that parent class, and then make our changes:

 /**
   * {@inheritdoc}
   */
  public function buildConfigurationForm(array $form, FormStateInterface $form_state) {
    $pluginForm = parent::buildConfigurationForm($form, $form_state);

    $options = $this->getConfigurationOptions($form['#entity']);

    if (empty($options)) {
      $pluginForm['drupal_field_value'] += [
        '#markup' => t('No available webform entity reference elements.'),
      ];
    }
    else {
      $pluginForm['drupal_field_value'] += [
        '#type' => 'select',
        '#options' => $options,
        '#empty_option' => $this->t('- Select -'),
        '#default_value' => $this->config('drupal_field_value'),
        '#description' => $this->t('Select a webform entity reference element.'),
      ];
    }
    // Just allowed to push.
    $pluginForm['direction']['#options'] = [
      MappingConstants::SALESFORCE_MAPPING_DIRECTION_DRUPAL_SF => $pluginForm['direction']['#options'][MappingConstants::SALESFORCE_MAPPING_DIRECTION_DRUPAL_SF],
    ];
    $pluginForm['direction']['#default_value'] =
      MappingConstants::SALESFORCE_MAPPING_DIRECTION_DRUPAL_SF;
    return $pluginForm;

  }

In this case we are using a helper function to get us a list of entity reference fields on this plugin (details are in the patch and unimportant to this discussion). We then make those fields the list of Drupal fields for the settings form. The array we got from the parent class already provides a list of Salesforce fields in $pluginForm[‘salesforce_field’] so we don’t have to worry about that part.  Since the salesforce_webform module is push-only on its mappings, this plugin was designed to be push only as well, and so limits to direction options to be push only. The default set of options is:

'#options' => [
    MappingConstants::SALESFORCE_MAPPING_DIRECTION_DRUPAL_SF => t('Drupal to SF'),
    MappingConstants::SALESFORCE_MAPPING_DIRECTION_SF_DRUPAL => t('SF to Drupal'),
    MappingConstants::SALESFORCE_MAPPING_DIRECTION_SYNC => t('Sync'),
 ],

And you can limit those anyway that makes sense for your plugin.

With the form array completed, we now move on to the value function. This is generally the most interesting part of the plugin since it does the work of actually setting the value returned by the mapping.

  /**
   * {@inheritdoc}
   */
  public function value(EntityInterface $entity, SalesforceMappingInterface $mapping) {
    $element_parts = explode('__', $this->config('drupal_field_value'));
    $main_element_name = reset($element_parts);
    $webform = $this->entityTypeManager->getStorage('webform')->load($mapping->get('drupal_bundle'));
    $webform_element = $webform->getElement($main_element_name);
    if (!$webform_element) {
      // This reference field does not exist.
      return;
    }

    try {

      $value = $entity->getElementData($main_element_name);

      $referenced_mappings = $this->mappedObjectStorage->loadByDrupal($webform_element['#target_type'], $value);
      if (!empty($referenced_mappings)) {
        $mapping = reset($referenced_mappings);
        return $mapping->sfid();
      }
    }
    catch (\Exception $e) {
      return NULL;
    }
  }

In this case we are finding the entity referred to in the webform submission, loading any mapping objects that may exist for that entity, and returning the Salesforce ID of the mapped object if it exists.  Yours will likely need to do something very different.

There are actually two related functions defined by the plugin interface, defined in the base class, and available for override as needed for setting pull and push values independently:

  /**
   * An extension of ::value, ::pushValue does some basic type-checking and
   * validation against Salesforce field types to protect against basic data
   * errors.
   *
   * @param \Drupal\Core\Entity\EntityInterface $entity
   * @param \Drupal\salesforce_mapping\Entity\SalesforceMappingInterface $mapping
   *
   * @return mixed
   */
  public function pushValue(EntityInterface $entity, SalesforceMappingInterface $mapping);

  /**
   * An extension of ::value, ::pullValue does some basic type-checking and
   * validation against Drupal field types to protect against basic data
   * errors.
   *
   * @param \Drupal\salesforce\SObject $sf_object
   * @param \Drupal\Core\Entity\EntityInterface $entity
   * @param \Drupal\salesforce_mapping\Entity\SalesforceMappingInterface $mapping
   *
   * @return mixed
   */
  public function pullValue(SObject $sf_object, EntityInterface $entity, SalesforceMappingInterface $mapping);


But be careful overriding them directly. The base class provides some useful handling of various data types that need massaging between Drupal and Salesforce, you may lose that if you aren’t careful. I encourage you to look at the details of both pushValue and pullValue before working on those.

Okay, with the configuration and values handled, we just need to deal with programmatically telling Drupal when it can pull and push these fields. Most of the time you don’t need to do this, but you can simplify some of the processing by overriding pull() and push() to make sure the have the right response hard coded instead of derived from other sources. In this case pulling the field would be bad, so we block that:

  /**
   * {@inheritdoc}
   */
  public function pull() {
    return FALSE;
  }

Also, we only want this mapping to appear as an option if the site has the webform module enabled. Without it there is no point in offering it at all. The plugin interface provides a function called isAllowed() for this purpose:

  /**
   * {@inheritdoc}
   */
  public static function isAllowed(SalesforceMappingInterface $mapping) {
    return \Drupal::service('module_handler')->moduleExists('webform');
  }

You can also use that function to limit a field even more tightly based on the mapping itself.

To further ensure the configuration of this mapping entity defines its dependencies correctly we can define additional dependencies in getDependencies(). Again here we are tied to the Webform module and we should enforce that during and config exports:

  /**
   * {@inheritdoc}
   */
  public function getDependencies(SalesforceMappingInterface $mapping) {
    return ['module' => ['webform']];
  }

And that is about it.  Once the class exists and is properly setup, all you need to do is rebuild the caches and you should see your new mapping field as an option on your Salesforce mapping objects (at least when isAllowed() is returning true).

In Praise of B Students

There is nothing wrong with just being good at something.

When I was in school I was a solid B student. I thought of myself as a B student and I worked hard to make sure I was always working at least a B average. I worked hard, but not too hard. I could have probably been an A student if I’d worked harder, but I would not have been as happy. I didn’t feel the drive to be the best all the time, just good enough to keep up with what I was learning. Most people brag about being A students, but that wasn’t me and it has worked out pretty well in the long run.

For me a B student is someone who not only gets actually Bs most of the time in school but also knows how to work hard to get the grade they want, and how to relax so they recover and enjoy their lives along the way. If they fall a little short at some point they are perfectly capable of working a little harder to make up the ground. Life is not a sprint, it’s a marathon, we all have to save a bit for later. If you are used to running full out all the time, you do not always have the ability to step it up a little extra when needed nor how to relax and recover without stopping. In a world where we seem to be moving from helicopter parents to snowplow parents, there are still people that have fallen short from time to time, so they know how to pick themselves up and push forward.

There has been plenty written and said about the flaws of perfectionism so you don’t need to trust me, and I’m not going to waste time making the case that there are problems with pushing kids and college students to be a perfect A student all the time. And there are problems when companies only want to hire people who have those backgrounds.

In our current test-driven education culture there is a lot of push for kids to be the best. And the highly competitive nature of admissions for some top colleges can make it seem like a kid has to be perfect to succeed in life. But life isn’t Top Gun there actually are points for second place, and really more or less all the others (well paychecks and some level of happiness anyway). More importantly people who are used to a bit of failure can excel when faced with tough jobs that require a lot of on the job learning and trial and error work. That describes pretty much every modern office job, and lots of others – watch a plumber work on an old house and you’ll see plenty of trial and error being required to solve even basic problems.

Failure is a part of life. We all need to know how to acknowledge we made mistakes, how to recover, and how to ensure we don’t make the same mistake again in the future. People who earned a lot of B’s in school are familiar with all those things. We sometimes got lazy and ended up with a C instead of B – to stay a B student we then worked harder and got ourselves enough A’s to offset our missteps and bring our averages back up. Sometimes we really didn’t understand something and had to struggle through to make sure we stayed on pace.

B students also often know the difference between learning and getting the right answer on an assessment (a skill I would have told you I had but did not need anymore until I starting having to pass professional certification exams on a regular basis). We learned how to pass the test without knowing all the information, but knowing enough to get the grade we wanted. Getting a perfect score on an assessment is only useful if the assessment is perfect – most college professors and anyone who has taken a certification exam can tell you there are no perfect assessments. I had to pass tests in college, and I need to complete and maintain certifications now, but I don’t need to have every piece of information crammed into my brain all the time – that’s what Google is for. Once I pass, I’ve passed – it feels better to get more right answers, but as long as I get enough to pass I’m certified.

When I was in the 6th grade we had a whole day dedicated to studies skills taught by a guy named Mr. Gallagher. He wasn’t a regular teacher at my school, and I have no idea where they found him or what happened to him later, but some of what he taught us that day has stuck with me both in terms of skills and philosophy. He emphasized the need to understand how a test was written, both in terms of following directions so you didn’t give up silly points and so you know where to focus your time (hint: time goes first into the places you are likely to earn the most points), and when to guess and when to work through an answer carefully (again be greedy about points not the number of right answers).

He was the first person to put the idea into my head that the point of going to school is to get good grades instead of learning. I can still remember our teachers pushing back on that argument the next day, and I eventually arrived at the conclusion that they were both right: the purpose of school is to learn, but the purpose of tests is to get good enough grades so you can move forward in school. The thought exercise itself helped me see that learning material and passing a test weren’t actually always related. I had a teacher later who helped me further abstract this concept when he pointed out that he could easily write tests we all passed or all failed, so the purpose of the test writing was to find a measure of what he thought we should be able to do (that teacher and his wife were recently on Marketplace – thanks Bill that simple lesson was super useful in college and beyond). If pass and fail are at the whim of the test author, and they aren’t actually playing against me personally but really tracking a group of people, then I can play it as a game where I need to get myself into the top 80%. If I learn to play at that level reliably I’m going to do pretty well and I don’t have to stress being perfect all the time.

Yes, there are things in life that you cannot do unless you are one of the best. Not to mention the fact that the playing field isn’t level, which means some people have to work a whole lot harder than others to earn the same B and a report card full of Bs doesn’t get read the same for everyone. But we cannot all be the best, and pretending that’s not true doesn’t level the social playing fields.

And of course there are plenty of moments we need to strive to be as close to perfect as we are capable. But we also have to hit deadlines and get things done even if we know the work will be less-than perfect. Anyone who works in software development has to deal with this on a regular basis. As much as we may want to be perfect, shifting project requirements, project timelines, platform weakness, and our own mistakes all get in the way. We do the best we can with the skills, time, teams, and the tools we have. We need to know how to accept that we cannot fix every flaw and still get things done well enough to ensure the project is successful.

So when you are hiring people consider looking for people who already know how to be second best. People who know how to do really good work, but also know how to take risks, try something new, and in the process fail. People who know how to get things done well enough to be successful, even if it’s not perfect. We aren’t perfect, our work isn’t perfect, our world isn’t perfect, so don’t pretend your team has to be perfect.

Authors Note: Last month I failed to post to this blog for the first time. If you look back over the record you will see at least one post each month from the time the blog starts through August 2019 – then I missed September. Oops. I could make all kinds of excuses (I really did get sick right at the end of the month so my planned post was delayed a week), but the truth is I had time and material, I just didn’t get anything done. So now to make up for it I am trying to post every weekend this month.  I missed a goal by a little, so now I compensate to make up for it – then I’ll hopefully go back to my nice reliable routine. What can I say? I’m okay with a B.

Arts in the Heart 2019

This year’s Arts in the Heart of Augusta was not hurricane plagued the way last year’s was, and was a great weekend of good food, performances, and generally great chances to take pictures.

Each year opens with a parade to celebrate the diverse set of communities that have settled in and around Augusta.

The whole event is built around artists selling their work. They manage to pull in people from a fairly large area, but also make space for young local artists to try to get started selling their work.

For us, and for many others, the variety of ethic foods available for purchase is a large part of the draw.

It’s also a great event for just plain people watching. Between watching the various performances, enjoying the vendors, and the many activities, there are lots of chances to watch people having a good time with their friends and family.

Mixed in with the vendors, food, family activities, stages, and other goes on are always a mix of street performers.

There are several stages setup throughout the event, spanning several city blocks. The performances range from local signers to dance troops, street performers

Until next year…

Two people walking away from the camera as the sun is setting. A few other people milling about.  The woman is wearing a traditional Mexican dress and hat.

SC DUG August 2019

After a couple months off, SC DUG met this month with a presentation on super cheap Drupal hosting.

Chris Zietlow from Mindgrub, Will Jackson from Kanopi Studios, and I all gave short talks very cheap ways to host Drupal 8.

Chris opened by talking about using AWS Micro servers. Will shared a solution using a Raspberry Pi for a fully wireless server. I closed the discussion with a review of using Drupal Tome on Netlify.

We all worked from a loose set of rules to help keep us honest and prevent overlapping:

Rules for Cheap D8 Hosting Challenge

The goal is to figure out the cheapest D8 hosting that would actually function for a project, even if it is deeply irresponsible to actually use.

Rules

  1. It has to actually work for D8 (so modern PHP version, working database, etc),
  2. You do not actually have to spend the money, but you do need to know all the steps required to make it work.
  3. It needs to honor the TOS for any networks and services you use (no illegal network taps – legal hidden taps are fair game).
  4. You have to share your idea with the other players so we don’t have two people propose the same solution (first-come-first-serve on ideas).

Reporting

Be prepared to talk for about 5 minutes on how your solution would work.  Your talk needs to include:

  1. Estimated Monthly cost for the first year.
  2. Steps required to make it work.
  3. Known weaknesses.

If you have a super cheap hosting solution for Drupal 8 we’d love to hear about it.

Drupal Tome + Docksal + Netlify

Drupal Tome is a static site generator distribution of Drupal 8. It provides mechanisms for taking an entire Drupal site and exporting all the content to HTML for direct service. As part of a recent competition at SCDUG to come up with the cheapest possible Drupal 8 hosting, I decided to do a proof-of-concept level implementation of Drupal 8 with Docksal for local content editing, and Netlify for hosting (total cost was just the domain registration).

The Tome project has directions for setup with Docker, and for setup with Netlify, but they don’t quite line up with each other (I followed the docker instructions, then the Netlify set, but had to chart my own course to get the site from the first project linked to the repo in the second), and since I’m getting used to using Docksal when I had to fall back and do a bit of it myself I realized it was almost painfully easy to setup.

The first step was to go to the Tome documentation for Netlify and setup an account, and site from the template. There is a button in those directions to trigger the Netlify setup, I’ve added one here as well (but if this one fails, check to see if they updated theirs):

Deploy to Netlify

Login with Github or similar service, and let it create a repo for your project.

Follow Netlify’s directions for setting up DNS so you can have the domain you want, and HTTPS (through Let’s Encrypt). It took it a couple hours to get that detail to run right, but it eventually worked. For this project I chose a subdomain of my main blog domain: tome-netlify.spinningcode.org

Next go to Github (or whatever service you used) and clone the repository to your local machine. There is a generated README on that project, but the directions aren’t 100% correct if you aren’t cloning onto a machine with a working PHP environment. This is when I switched over to docksal, and ran the following series of commands:

fin init
fin composer install
fin drush tome:install
fin drush uli

Then log into your local site using the domain from docksal and the link from drush, and add some content.

Next we export the content from Drupal to send over to Netlify for deployment.

fin drush tome:static
git add .
git commit -m "Adding sample content"
git push

…now we wait while Netlify notices and builds the site…

If you look at the site a few minutes later the new content should be posted.

This is all well and good if I want to use the version of the site generated for the Netlify example, but I wanted to make sure I could do something more interesting. These days Drupal ships with an install profile called Unami that provides a more robust sample site than the more traditional Standard install.

So now let’s try to get Unami onto this site. Go back to the terminal and have Tome reset everything (it’ll warn you that you are about to nuke everything):

fin drush tome:init

…select Unami when it asks for a profile…and wait cause this takes a while…

Now just re-export the content and push it to your repo.

fin drush tome:static
git add .
git commit -m "Converting to Unami"
git push

And wait again, cause this also takes a few minutes…

The Unami home page on my subdomain hosted at Netlify.

That really was all that was involved for a simple site, you can see my repository on Github if you want to see all of what was generated along the way.

The whole process is pretty straight forward, but there are a few things that it helps to understand.

First, Netlify is actually regenerating the markup on their servers with this approach. The Drupal nodes, and other entities, are saved as JSON and then imported during the build. This makes the process reliable, but slow. Unami takes several minutes to deploy since Netlify is installing and configuring Drupal, loading the content, and generating the output. The build command provided in that template is clear enough to follow if you are familiar with composer projects:

command = "composer install && ./vendor/bin/drush tome:install -y && ./vendor/bin/drush tome:static -l $DEPLOY_PRIME_URL"

One upside of this, is that you can use a totally unrelated domain for your local testing and have it adjust correctly to the production domain. When you are using Netlify’s branching workflow for managing dev, test, and production it also protects your work that way.

My directions above load a standard docksal container because that’s quick and easy, which includes MySQL, but Tome falls back to using a Sqlite database since you can be more confident it is there. Again this is reliable but slow. If I were going to do this on a more complete project I’d want a smaller Docksal setup or to switch to using MySQL locally.

A workflow based on this approach might also struggle with concurrent edits or complex configuration of large sites. It would probably make more sense to have the content created on a hidden, but traditional, server and then run through a different workflow. But for someone working on a series small sites that are rarely updated, a totally temporary instance of the site that can be rapidly deployed to a device, have content updated, push out to production, and then deleted locally until needed again.

The final detail to note is that there is no support for forms built into this solution. Netlify has support for that, and Tome has a module that claim to connect to that service but I wasn’t able to quickly determine how to get it connected. I am confident there are solves to this problem, but it is something that would take a little additional work.

Bypass Pantheon Timeouts for Drupal 8

Pantheon is an excellent hosting service for both Drupal and WordPress sites. But to make their platform work and scale well they have set a number of limits built into the platform, these include process time limits and memory limits that are large enough for the vast majority of projects, but from time to time run you into trouble on large jobs.

For data loading and updates their official answer is typically to copy the database to another server, run your job there, and copy the database back onto their server. That’s fine if you can afford to freeze updates to your production site, setup a process to mirror changes into your temporary copy, or some other project overhead that can be limiting and challenging. But sometimes that’s not an option, or the data load takes too long for that to be practical on a regular basis.

I recently needed to do a very large import for records into a Drupal database and so started to play around with solutions that would allow me to ignore those time limits. We were looking at needing to do about 50 million data writes and the running time was initially over a week to complete the job.

Since Drupal’s batch system was created to solve this exact problem it seemed like a good place to start. For this solution you need a file you can load and parse in segments, like a CSV file, which you can read one line at a time. It does not have to represent the final state, you can use this to actually load data if the process is quick, or you can serialize each record into a table or a queue job to actually process later.

One quick note about the code samples, I wrote these based on the service-based approach outlined in my post about batch services and the batch service module I discussed there. It could be adapted to a more traditional batch job, but I like the clarity the wrapper provides for breaking this back down for discussion.

The general concept here is that we upload the file and then progressively process it from within a batch job. The code samples below provide two classes to achieve this, first is a form that provides a managed file field which create a file entity that can be reliably passed to the batch processor. From there the batch service takes over and using a bit of basic PHP file handling to load the file into a database table. If you need to do more than load the data into the database directly (say create complex entities or other tasks) you can set up a second phase to run through the values to do that heavier lifting.

To get us started the form includes this managed file:

   $form['file'] = [
     '#type' => 'managed_file',
     '#name' => 'data_file',
     '#title' => $this->t('Data file'),
     '#description' => $this->t('CSV format for this example.'),
     '#upload_location' => 'private://example_pantheon_loader_data/',
     '#upload_validators' => [
       'file_validate_extensions' => ['csv'],
     ],
   ];

The managed file form element automagically gives you a file entity, and the value in the form state is the id of that entity. This file will be temporary and have no references once the process is complete and so depending on your site setup the file will eventually be purged. Which all means we can pass all the values straight through to our batch processor:

$batch = $this->dataLoaderBatchService->generateBatchJob($form_state->getValues());

When the data file is small enough, a few thousand rows at most, you can load them all right away without the need of a batch job. But that runs into both time and memory concerns and the whole point of this is to avoid those. With this approach we can ignore those and we’re only limited by Pantheon’s upload file size. If they file size is too large you can upload the file via sftp and read directly from there, so while this is an easy way to load the file you have other options.

As we setup the file for processing in the batch job, we really need the file path not the ID. The main reason to use the managed file is they can reliably get the file path on a Pantheon server without us really needing to know anything about where they have things stashed. Since we’re about to use generic PHP functions for file processing we need to know that path reliably:

$fid = array_pop($data['file']);
$fileEntity = File::load($fid);
$ops = [];

if (empty($fileEntity)) {
  $this->logger->error('Unable to load file data for processing.');
  return [];
}
$filePath = $this->fileSystem->realpath($fileEntity->getFileUri());
$ops = ['processData' => [$filePath]];

Now we have a file and since it’s a csv we can load a few rows at time, process them, and then start again.

Our batch processing function needs to track two things in addition to the file: the header values and the current file position. So in the first pass we initialize the position to zero and then load the first row as the header. For every pass after that we need to find point we left off. For this we use generic PHP files for loading and seeking the current location:

// Old-school file handling.
$path = array_pop($data);
$file = fopen($path, "r");
...
fseek($file, $filePos);

// Each pass we process 100 lines, if you have to do something complex
// you might want to reduce the run.
for ($i = 0; $i < 100; $i++) {
  $row = fgetcsv($file);
  if (!empty($row)) {
    $data = array_combine($header, $row);
    $member['timestamp'] = time();
    $rowData = [
             'col_one' => $data['field_name'],
             'data' => serialize($data),
             'timestamp' => time(),
    ];
    $row_id = $this->database->insert('example_pantheon_loader_tracker')
             ->fields($rowData)
             ->execute();

    // If you're setting up for a queue you include something like this.
    // $queue = $this->queueFactory->get(‘example_pantheon_loader_remap’);
    // $queue->createItem($row_id);
 }
 else {
   break;
 }
}
$filePos = (float) ftell($file);
$context['finished'] = $filePos / filesize($path);

The example code just dumps this all into a database table. This can be useful as a raw data loader if you need to add a large data set to an existing site that’s used for reference data or something similar.  It can also be used as the base to create more complex objects. The example code includes comments about generating a queue worker that could then run over time on cron or as another batch job; the Queue UI module provides a simple interface to run those on a batch job.

I’ve run this process for several hours at a stretch.  Pantheon does have issues with systems errors if left to run a batch job for extreme runs (I ran into problems on some runs after 6-8 hours of run time), so a prep into the database followed by running on queue or something else easier to restart has been more reliable.

Docksal Pantheon Setup from Scratch

I recently had reason to switch over to using Docksal for a project, and on the whole I really like it as a good easy solution for getting a project specific Drupal dev environment up and running quickly. But like many dev tools the docs I found didn’t quite cover what I wanted because they made a bunch of assumptions.

Most assumed either I was starting a generic project or that I was starting a Pantheon specific project – and that I already had Docksal experience. In my case I was looking for a quick emergency replacement environment for a long-running Pantheon project.

Fairly recently Docksal added support for a project init command that helps setup for Acquia, Pantheon, and Pantheon.sh, but pull init isn’t really well documented and requires a few preconditions.

Since I had to run a dozen Google searches, and ask several friends for help, to make it work I figured I’d write it up.

Install Docksal

First follow the basic Docksal installation instructions for your host operating system. Once that completes, if you are using Linux as the host OS log out and log back in (it just added your user to a group and you need that access to start up docker).

Add Pantheon Machine Token

Next you need to have a Pantheon machine token so that terminus can run within the new container you’re about to create. If you don’t have one already follow Pantheon’s instructions to create one and save if someplace safe (like your password manager).

Once you have a machine token you need to tell Docksal about it.  There are instructions for that (but they aren’t in the instructions for setting up Docksal with pull init) basically you add the key to your docksal.env file:

SECRET_TERMINUS_TOKEN="HASH_VALUE_PROVIDED_BY_PANTHEON_HERE"

 Also if you are using Linux you should note that those instructions linked above say the file goes in $HOME/docksal/docksal.env, but you really want $HOME/.docksal/docksal.env (note the dot in front of docksal to hide the directory).

Setup SSH Key

With the machine token in place you are almost ready to run the setup command, just one more precondition.  If you haven’t been using Docker or Docksal they don’t know about your SSH key yet, and pull init assumes it’s around.  So you need to tell Docksal to load it but running:
fin ssh-key add

If the whole setup is new, you may also need to create your key and add it to Pantheon.  Once you have done that, if you are using a default SSH key name and location it should pick it up automatically (I have not tried this yet on Windows so mileage there may vary – if you know the answer please leave me a comment). It also is a good idea to make sure the key itself is working right but getting the git clone command from your Pantheon dashboard and trying a manual clone on the command line (delete once it’s done, this is just to prove you can get through).

Run Pull Init

Now finally you are ready to run fin pull init:

fin pull init --hostingplatform=pantheon --hostingsite=[site-machine-name] --hosting-env=[environment-name]

Docksal will now setup the site, maybe ask you a couple questions, and clone the repo. It will leave a couple things out you may need: database setup, and .htaccess.

Add .htaccess as needed

Pantheon uses nginx.  Docksal’s formula uses Apache. If you don’t keep a .htaccess file in your project (and while there is not reason not to, some Pantheon setups don’t keep anything extra stuff around) you need to put it back. If you don’t have a copy handy, copy and paste the content from the Drupal project repo:  https://git.drupalcode.org/project/drupal/blob/8.8.x/.htaccess

Finally, you need to tell Drupal where to find the Docksal copy of the database. For that you need a settings.local.php file. Your project likely has a default version of this, which may contain things you may or may not want so adjust as needed. Docksal creates a default database (named default) and provides a user named…“user”, which has a password of “user”.  The host’s name is ‘db’. So into your settings.local.php file you need to include database settings at the very least:

<?php
$databases = array(
  'default' =>
    array(
      'default' =>
      array(
        'database' => 'default',
        'username' => 'user',
        'password' => 'user',
        'host' => 'db',
        'port' => '',
        'driver' => 'mysql',
        'prefix' => '',
      ),
    ),
);

With the database now fully linked up to Drupal, you can now ask Docksal to pull down a copy of the database and a copy of the site files:

fin pull db

fin pull files

In the future you can also pull down code changes:

fin pull code

Bonus points: do this on a server.

On occasion it’s useful to have all this setup on a remote server not just a local machine. There are a few more steps to go to do that safely.

First you may want to enable Basic HTTP Auth just to keep away from the prying eyes of Googlebot and friends.  There are directions for that step (you’ll want the Apache instructions). Next you need to make sure that Docksal is actually listing to the host’s requests and that they are forwarded into the containers.  Lots of blog posts say DOCKSAL_VHOST_PROXY_IP=0.0.0.0 fin reset proxy. But it turns out that fin reset proxy has been removed, instead you want:

DOCKSAL_VHOST_PROXY_IP=0.0.0.0 fin system reset.

Next you need to add the vhost to the docksal.env file we were working with earlier:

 VIRTUAL_HOST="test.example.org"

Run fin up to get Docksal to pick up the changes (this section is based on these old instructions).

Now you need to add either a DNS entry someplace, or update your machine’s /etc/hosts file to look in the right place (the public IP address of the host machine).

Anything I missed?

If you think I missed anything feel free to let know. Particularly Windows users feel free to let me know changes related to doing things there. I’ll try to work those in if I don’t get to figuring that out on my own in the near future.

SC DUG May 2019

For this month’s SC DUG, Mauricio Orozco from the South Carolina Commission for Minority Affairs shared his notes and lessons learned during his first DrupalCon North America.

We frequently use these presentations to practice new presentations, try out heavily revised versions, and test out new ideas with a friendly audience. If you want to see a polished version checkout our group members’ talks at camps and cons. So if some of the content of these videos seems a bit rough please understand we are all learning all the time and we are open to constructive feedback.

If you would like to join us please check out our up coming events on Meetup for meeting times, locations, and connection information.

Hague Appeal for Peace Pictures

This week marks the 20th Anniversary of the Hague Appeal for Peace.

This week marks the 20th anniversary of the Hague Appeal for Peace and everything that happened (and didn’t) as part of that event and since, I decided to post some of my pictures from that adventure.

In my post on being an activist back in March I mentioned attending the Hague Appeal and the peace walk that followed. I was part of a delegation from Philadelphia Yearly Meeting; a group mostly made up of college students and a few older high school students, along with a few adults who handled the logistics and kept us on track more or less.

I have ten boxes of slides, and a few years ago I scanned them as best I could but frankly the scans aren’t great. The slides, which were more than ten years old at the time, had already started to fade and color shift as a result of their age. I did some color correction as I prepped them for this, but I also like the feel of some being somewhat faded and shifted with time. There are shared here full frame, and some are roughly cropped, but none carefully realigned. Since they are now pushing twenty I decided that I wanted to leave them all at or near full size and try to capture a bit of the way I saw the world then, and less of how I would edit it now. I like the rough visual feel they have as part of reflected on partially faded memories.

That trip was an important few weeks in my life, and I’ve been having a great time going back through the pictures. If you were with me on that trip and wonder if I have other pictures of you kicking around I might so send me a note and I’ll try to see what’s around and sent some your way.

FormAssembly Dynamic Parameter Signing

For a project I’ve been working on recently we had need to create a module that provides secure redirects from a Drupal site to FormAssembly. Overall the module does a number of things, but handling dynamic parameter signing was the thing that took the most time.

FormAssembly provides a variety of great features for creating flexible forms that integrate with Salesforce. One of the more popular features is its ability to pull data from Salesforce to prefill fields on a form. But the downside is that it is easy to create forms that leak information from Salesforce into those forms, and create privacy risks.

To address this, FormAssembly allows 3rd party tools to securely sign URLs that contain parameters (often Salesforce IDs) that could be used to extract information through an iteration attack and other basic approaches. This secure signing process can be done statically but for most interesting projects you want to sign the URLs dynamically. The dynamic signing process allows you alter the parameters on the fly and set an expiration date to limit the value of a stolen link. Our project required this approach.

But the dynamic signing process has a couple sharp corners. First, it’s rarely done outside of Salesforce so there aren’t a lot of code samples around, and none that I could find in PHP.  Second, FormAssembly is very open and honest about the fact that they do not provide support on this feature. So I had to create my own process from the documentation they provide.  The docs are good, but very Salesforce centric, with all code samples in APEX.

The process involves preparing the data for signature, generating a HMAC-SHA256 with a form specific pre-shared key (in binary mode), converted to a string using base64, and finally URL encode the result.

Their convention for preparing the data is straightforward. You format all parameters as just their key and value strung together: key1Value1key2Value2

The interesting part is the actual HMAC-SHA256, which needs to be generated in binary mode, something that is often the default mode but not in PHP (in fact most PHP devs I’ve talked don’t realize the last parameter to hash_hmac() is useful, if you are doing this in another language check out this collection of examples).

From there you encode the output in base-64 (which results in a 44 character hash), and URL encode the hash to make sure it’s URL safe, and you’ll end up a few characters longer.

Finally you add you hash to the query string, and you’re ready to go.

To help anyone else who needs to do this, I generalized this part of the solution and I created and tossed it into Gist.
